Specifications
|
Item No |
VD-12150D0243 |
VD-24150D0243 |
|
Output Voltage |
12V |
24V |
|
Output Current |
12.5A |
6.25A |
|
Rated power |
150W |
|
|
Input Voltage |
90~264Vac or 127~374Vdc |
|
|
Efficiency Typ.) |
88.00% |
90.00% |
|
Power factor |
PF≥0.5/110V(at full load) PF≥0.45/230V(at full load) |
|
|
Waterproof Rating |
IP67 |
|
|
Warranty |
2/3 years |
|
|
Certificate |
CE, Rohs, UL |
|
|
Working temperature |
-25°C~+50°C |
|
|
Working humidity |
10%~90%RH, No Condensation |
|
|
Storage temperature and humidity |
-25°C~+75°C, 5%~95%RH |
|
|
Dimension |
256X67.5X44.8mm(L*W*H) |
|
|
Package |
1.3Kg/PCS, 10PCS/13Kg/box, (320X295X195mm) |
|
Should you need specific data sheet, certificate files, dimensions drawing, temperature load curve, input voltage load curve, kindly please contact us.
Features
Protection function from: short circuit / over load / over voltage / over temperature
IP67 waterproof design for indoor and outdoor installation
It can be applied to dry, wet, damp and rainy environment
Cooling by free air, high reliability
100% full load burn-in test
Suitable for internal lights application for I/II/III
It could be widely used in LED lighting and IT equipment
Compliance to world wide safety regulation for LED lighting, including US & Canada standard of UL certificate.
Application
This 150w power supply is compatible with kinds of LED linear lighting, led strip lighting, led downlight, street lamp, garden lamp, lawn lamp, underground lamp, green ground lamp, moisture-proof lamp, underwater lamp, pool lamp, landscape lamp, gardening lamp etc.
Support
1.Quality promise, new product could be sent and replaced if defective happen during the warranty period.
2.We could provide free sample for testing within 7 days per your request. Customers should take care of the shipment freight.
3.Our general lead time is 30 days, several days of difference according to the actual situation.
