Item No

VA-12030D0952

VA-24030D0952

VAS-12030D0185

VAS-24030D0185

Output Voltage

12V

24V

12V

24V

Output Current

2.5A

1.25 A

2.5A

1.25 A

Rated power

30W

Input Voltage

170~264Vac or 240~374Vdc

Efficiency Typ.)

85.50%

86.00%

83.50%

84.50%

Power factor

PF≥0.5/230Vac (at full load)

PF≥0.9/230V(at full load)

Waterproof Rating

IP67

Warranty

2/3/5 years

Certificate

CE, Rohs, BIS

CE, Rohs, BIS, EMC

Working temperature

-25°C~+50°C

Working humidity

10%~90%RH, No Condensation

Storage temperature and humidity

-25°C~+75°C, 5%~95%RH

Dimension

182*29*20.5mm(L*W*H)

217X36.5X27mm(L*W*H)

Package

0.2Kg/PCS； 50PCS/Ctn OKg/box； (395*215*180mm)

0.38Kg/PCS, 50PCS/19Kg/box, (325X260X270mm)

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Derating may be needed under low input voltages. Please check the static characteristics for more details.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
4. Ripple & noise are measured at 20MHZ of bandwidth by using twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
5.The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will
be affected by the complete installation, the final equipment manufacturers must re-confirm EMC Directive on the complete installation.
6.The start time was tested under the situation of cold star, continuous switching on/off may raise the start time.
